Embassy Fire Extinguisher Cabinets feature the most elegant door style in our product line and a decorative, trimless, recessed cabinet suitable for the most upscale application in our finest finishes of Bronze, Brass, Stainless Steel, Painted Steel, or Aluminum to match your décor.
This series includes sizes for fire extinguishers and three sizes to fit fire department valves and hoses. All models comply with ADA projection requirements.
Embassy Fire Extinguisher Cabinet Specifications
- Door and Trim Construction: These 7/8″ formed design fire extinguisher cabinet doors are available in # 4 satin stainless steel, US 10 satin bronze, US 3 polished brass, # 180 clear anodized aluminum, or powder-coated white steel. The doors feature a continuous concealed hinge, concealed handle, and roller catch.
- Trim Style and Depth: None
- Tub: Constructed of cold rolled steel with white powder-coat finish standard.
- Unique Options: The 5900 Series Fire Department Valve, Hose, and Extinguisher Cabinets are equipped with a shelf “2” from the bottom. Knockouts are located “6” from the bottom and 4-1 “4” from the back on both the right and left-hand sides.
- Fire Rated Option: Yes
Fire Extinguisher Cabinet Options
- Aluminum Tub with Mill Finish for Non-Rated Use.
- Color Painted Door or Tub – Steel Only.
- Etched or Engraved Lettering on Glass or Metal. (Color fill Optional)
- Fire Extinguisher Lettering In Black, Red, or White.
- FIRE -FX Fire-Rated Tub Option.
- Futura Emboss” d “F” re” Handle. – Mill or White
- Wall Signs and Labels.
- Color Anodized Aluminum.
- #6, #7 or #8 Stainless Steel US 9 Polished Bronze Door-Clear Coated.
- US 10B Oil-Rubbed Bronze Door.
- US 4 Satin Brass Door-Clear Coated.
Model Number | Style |
5624 | Recessed |
5724 | Recessed |
5624-FX2 | Fire Rated, Recessed |
5724-FX2 | Fire Rated, Recessed |
Photo Description: A. Embassy Series, Stainless Steel, with a sold door, 5634S21FX. B. Embassy Series, Brass with Vertical duo pull handle.
Contact us for more information on custom sizes, options, and fire extinguisher cabinets.
