The Steel Network TSN DriftClip® DSL (Drift Slide Angle Exterior Head of Wall) connects exterior cold-formed steel curtain wall studs to the slab at the head of wall while allowing for 2″ vertical deflection (1″ up and down) and 2″ lateral drift (1″ left and right-in-plane). TSN’s patented Step Up Bushing Technology provides an anti-friction and anti-seizure connection between the clip and both the stud web surface and track.
DriftClip® DSL (Drift Slide Angle Exterior Head of Wall) Features
- Load-rated positive mechanical attachment at each stud
- Eliminates loose friction-held assemblies, heavy deep-leg track, and top row of wall bridging/strapping.
- Load-rated #12 screws provide for vertical deflection connection to stud web
- Manufactured with certified, 50ksi, 97 mil, G90 cold-formed steel
- Step Bushings pre-installed for accurate placement.
- Rated screws provided.
- Load transferred from stud web.
- Meets all building code criteria.
- Adaptable for multiple configurations.
